1
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Interface/Connectivity IP: USB Host/Device Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
2
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Interface/Connectivity IP: Ethernet Media Access Controller(10/100Mbps)
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
3
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Interface/Connectivity IP: Gigabit Ethernet Media Access Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
4
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Memory Controller IP: Static Memory Controller (SRAM/NOR/eMMC)
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
5
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Memory Controller IP: Direct Memory Access Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
6
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Memory Controller IP: SD Host Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
7
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
System/Peripheral IP: General Purpose Input-Output Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
8
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
System/Peripheral IP: Serial Peripheral Interface Master Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
9
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Processor IP: VEGA ET1031: 32-bit Microprocessor
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
10
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Processor IP: VEGA AS1061: 64-bit Microprocessor
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
11
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Processor IP: VEGA AS1161: 64-bit Microprocessor
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
12
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Processor IP: VEGA AS2161: 64-bit Microprocessor
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
13
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Processor IP: VEGA AS4161: 64-bit Microprocessor
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
14
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Processor IP: VEGA AT1051: 32-bit Microprocessor
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
16
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Basic Function IP: Timer
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
17
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Basic Function IP: UART
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
18
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Basic Function IP: Platform Level Interrupt Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
19
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Basic Function IP: Inter-Integrated Circuit Master Controller
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
20
Provider Name: CDAC-TVM
IP Type: Soft IP
Support:vega[at]cdac[dot]in
Basic Function IP: Pulse Width Modulator
Maturity Level: Silicon Proven
Provided with core: Design Files, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: N/A
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
21
Provider Name: Incore Semiconductors
IP Type: Soft IP
Support:madhu[at]incoresemi[dot]com
Standard Bus IP: AXI4 Cross-bar Interconnect
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench, Constraint File, Simulation Model
Tested design flows: Design Entry, Simulation & Verification, Synthesis, Benchmarks & Performance
Technical Documents: Datasheets: Interconnect
22
Provider Name: Incore Semiconductors
IP Type: Soft IP
Support:madhu[at]incoresemi[dot]com
Processor IP: Chromite Core Generator
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: Design Entry, Simulation & Verification, Synthesis, Benchmarks & Performance
Technical Documents: Datasheets: Chromite, Azurite
23
Provider Name: Incore Semiconductors
IP Type: Soft IP
Support:madhu[at]incoresemi[dot]com
Processor IP: Azurite Core Generator
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench, Constraint File, Simulation Model, Supported Drivers
Tested design flows: Design Entry, Simulation & Verification, Synthesis, Benchmarks & Performance
Technical Documents: Datasheets: Chromite, Azurite
24
Provider Name: Incore Semiconductors
IP Type: Soft IP
Support:madhu[at]incoresemi[dot]com
Security IP: AES[128/192/256]
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench, Constraint File, Simulation Model
Tested design flows: Design Entry, Simulation & Verification, Synthesis, Benchmarks & Performance
Technical Documents: N/A
25
Provider Name: Incore Semiconductors
IP Type: Soft IP
Support:madhu[at]incoresemi[dot]com
Security IP: SHA[256/512]
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench, Constraint File, Simulation Model
Tested design flows: Design Entry, Simulation & Verification, Synthesis, Benchmarks & Performance
Technical Documents: N/A
26
Provider Name: Incore Semiconductors
IP Type: Soft IP
Support:madhu[at]incoresemi[dot]com
Security IP: RSA
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench, Constraint File, Simulation Model
Tested design flows: Design Entry, Simulation & Verification, Synthesis, Benchmarks & Performance
Technical Documents: N/A
27
Provider Name: Incore Semiconductors
IP Type: Soft IP
Support:madhu[at]incoresemi[dot]com
Security IP: ECC
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench, Constraint File, Simulation Model
Tested design flows: Design Entry, Simulation & Verification, Synthesis, Benchmarks & Performance
Technical Documents: N/A
28
Provider Name: CDAC-Hyderabad
IP Type: Verification IP
Support:anoopkr[at]cdac[dot]in
Verification IP: CCI(Cache Coherrant Interconnect)
Maturity Level: Product
Provided with core: Test Bench
Tested design flows: Simulation & Verification
Technical Documents: User Guides
29
Provider Name: CDAC-Hyderabad
IP Type: Verification IP
Support:anoopkr[at]cdac[dot]in
Verification IP: SD Host Controller
Maturity Level: Product
Provided with core: Test Bench
Tested design flows: Simulation & Verification
Technical Documents: User Guides
30
Provider Name: MosChip Technologies Public Limited
IP Type:Soft IP
Support:sales[at]moschip[dot]com
Analog IP:Power Management
Maturity Level:Prototype
Provided with core: Design Files,Example Designs,Test Bench,Simulation Tool
Tested design flows: Simulation & Verification
Technical Documents: Release Notes & Known Issues,DataSheets,User Guides
31
Provider Name: MosChip Technologies Public Limited
IP Type:Soft IP
Support:sales[at]moschip[dot]com
Analog IP:Clock Management
Maturity Level:Prototype
Provided with core: Design Files,Example Designs,Test Bench,Simulation Tool
Tested design flows: Simulation & Verification
Technical Documents: Release Notes & Known Issues,DataSheets,User Guides
32
Provider Name: MosChip Technologies Public Limited
IP Type:Soft IP
Support:sales[at]moschip[dot]com
Analog IP:LCD Panel Controller
Maturity Level:Prototype
Provided with core: Design Files,Example Designs,Test Bench,Simulation Tool
Tested design flows: Simulation & Verification
Technical Documents: Release Notes & Known Issues,DataSheets,User Guides
33
Provider Name: MosChip Technologies Public Limited
IP Type:Soft IP
Support:sales[at]moschip[dot]com
Analog IP:Temperature Sensor
Maturity Level:Prototype
Provided with core: Design Files,Example Designs,Test Bench,Simulation Tool
Tested design flows: Simulation & Verification
Technical Documents: Release Notes & Known Issues,DataSheets,User Guides
34
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP: PCIe Gen 1 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
35
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP: PCIe Gen 1 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
36
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP: PCIe Gen 2 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
37
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP: PCIe Gen 2 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
38
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 3 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
39
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 3 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
40
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 4 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
41
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 4 EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
42
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 5 EP/RC/ DM
Maturity Level: Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
43
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 5 EP/RC/ DM
Maturity Level: Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
44
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 6 EP/RC/ DM
Maturity Level: Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
45
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 6 EP/RC/ DM
Maturity Level: Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
46
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 7 EP/RC/ DM
Maturity Level: Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
47
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIe Gen 7 EP/RC/ DM
Maturity Level: Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
48
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:CXL V1.x EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
49
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:CXL V1.x EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
50
Provider Name:PRIMESOC Technologies
IP Type: Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:CXL V2.x EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
51
Provider Name:PRIMESOC Technologies
IP Type: Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:CXL V2.x EP/RC/ DM
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
52
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:CXL V3.x EP/RC/ DM
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
53
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:CXL V3.x EP/RC/ DM
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
54
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:UCIe 1.x EP/RC/ DM
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
55
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:UCIe 1.x EP/RC/ DM
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
56
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIE Retimer Gen4/5/6/7
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
57
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIE Retimer Gen4/5/6/7
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
58
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIE Switch G1/2/3/4/5/6/7
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
59
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Interface/Connectivity IP:PCIE Switch G1/2/3/4/5/6/7
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
60
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Audio,Video & Image Processing IP:MIPI CSI TX/RX
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
61
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Audio,Video & Image Processing IP:MIPI CSI TX/RX
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
62
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Audio,Video & Image Processing IP:MIPI DSI TX/RX
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
63
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Audio,Video & Image Processing IP:MIPI DSI TX/RX
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
64
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Standerd Bus IP: AXI4 Memory map
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
65
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Standerd Bus IP:AXI4 Memory map
Maturity Level:Others
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
66
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Standard Bus IP:AXI4 Stream
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
67
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Standard Bus IP:AXI4 Stream
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
68
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Standard Bus IP:APB
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
69
Provider Name:PRIMESOC Technologies
IP Type:Verification IP
Support:ijd[at]primesoctechnologies[dot]com
Standard Bus IP:APB
Maturity Level: Prototype
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance,Supported Device,Tools
Technical Documents: Release Notes & Known Issues, Datasheets, User Guides
70
Provider Name:PRIMESOC Technologies
IP Type:Soft IP
Support:ijd[at]primesoctechnologies[dot]com
Security IP: AES_GCM
Maturity Level: FPGA Prototypes Available
Provided with core: Design Files, Example Designs, Test Bench,Constraint File, Simulation Model
Tested design flows: Design Entry,Simulation & Veriifcation,Synthesis,Benchmarks & Performance
71
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:GNSS FEM: 4 Channel LNA supporting 1/L5/S bands for NavIC, GPS, GLONASS, and BeiDou constellations;
Maturity Level:Silicon Proven
Provided with core:Design Files, Example Designs, Test Bench, Simulation Model
Tested design flows: Schematic → EM → PVT Sim → Layout→Post-Layout
Technical Documents:Release Notes, Datasheet, User Guide, Evalboard Design
72
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:5G Small Cell FEM: 700 MHz to 6 GHz wideband GaAs LNA
Maturity Level:Silicon Proven
Provided with core: Design Files, Example Designs, Test Bench, Simulation Model
Tested design flows: Schematic → EM → PVT Sim → Layout→Post-Layout
Technical Documents: Release Notes, Datasheet, User Guide, Evalboard Design
73
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Sub-1 GHz Transceiver : RFIC 140 MHz to 1 GHz
Maturity Level:Silicon
Provided with core:Design Files, Example Designs, Test Bench, Constraint File, Simulation Model
Tested design flows: Schematic → EM → PVT Sim → Layout→Post-Layout
Technical Documents: Release Notes, Datasheet, User Guide, Evalboard Design
74
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:GNSS RFIC: RFIC 1.175 GHz to 1.575 GHz
Maturity Level:Schematic
Provided with core: Target Specification
Tested design flows: NA
Technical Documents: NA
75
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ku LNA (13.75 -14.5GHz)
Maturity Level:Silicon Proven
Provided with core:Target Specification
Tested design flows: NA
Technical Documents: NA
76
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ka LNA (27 -31GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
77
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ku PA 100mW (13.75 -14.5GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
78
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ka PA 100mW (27 -31GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
79
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ku PA 7W (10.9 -12.7GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
80
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ka PA 7W (17 -21.2GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
81
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ku PA 10W (10.9 -12.7GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
82
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP:Leo Satcomm RF Component: Ka PA 10W (17 -21.2GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
83
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: Leo Satcomm RF Component: Ku PA 25W (10.9 -12.7GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
84
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: Leo Satcomm RF Component: Ka PA 25W (17 -21.2GHz)
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
85
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: Mixer S/Ku/Ka
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
86
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: PLL IP: 0.7-1.5G, low power PLL for display driver MCU
Maturity Level:Layout
Provided with core:Design Files, Example Designs, Test Bench, Constraint File, Simulation Model
Tested design flows:Schematic → EM → PVT Sim → Layout→Post-Layout
Technical Documents:Release Notes, Datasheet, User Guide
87
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: PLL IP: Low phase noise PLL for GNSS bands
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
88
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: PLL IP: Low Phase noise wideband PLL for SubGHz
Maturity Level:Silicon
Provided with core:Design Files, Example Designs, Test Bench, Simulation Model
Tested design flows:Schematic → EM → PVT Sim → Layout→Post-Layout
Technical Documents:Release Notes, Datasheet
89
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: ADC IP: 10bit, 10 Mhz, 20MSPS
Maturity Level:Silicon
Provided with core:Design Files, Example Designs, Test Bench, Simulation Model
Tested design flows:Schematic → EM → PVT Sim → Layout→Post-Layout
Technical Documents:Release Notes, Datasheet
90
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: ADC IP: 2bit, 10 Mhz, 20MSPS
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
91
Provider Name: Silizium Circuits
IP Type:Hard IP
Support:info[at]siliziumcircuits[dot]
Analog IP: ADC IP: 14bit, 2MSPS
Maturity Level:Schematic
Provided with core:Target Specification
Tested design flows:NA
Technical Documents:NA
93
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in; harsh[at]scl[dot]gov[dot]in; munish[at]scl[dot]gov[dot]in;ajay_k[at]scl[dot]gov[dot]in
Interface/Connectivity IP: LVDS Receiver1 (400 Mbps)
Maturity Level: Silicon Proven
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Simulation Datasheet
94
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; munish[at]scl[dot]gov[dot]in;ajay[at]scl[dot]gov[dot]in
Interface/Connectivity IP: LVDS Transmitter1 (400 Mbps)
Maturity Level: Silicon Proven
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents:Simulation Datasheet
95
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; anuj[at]scl[dot]gov[dot]in;basra[at]scl[dot]gov[dot]in
Memory IP: Standard 4LM SPRAM Cuts (17)
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files and All EDA views
Tested design flows: Simulation, Physical Verification
Technical Documents: Generic Datasheets
96
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; anuj[at]scl[dot]gov[dot]in;basra[at]scl[dot]gov[dot]in
Memory IP: Standard 6LM SPRAM Cuts (20)
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files and All EDA views
Tested design flows: Simulation, Physical Verification
Technical Documents: Generic Datasheets
97
Provider Name: SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; anuj[at]scl[dot]gov[dot]in;basra[at]scl[dot]gov[dot]in
Memory IP: Standard 4LM DPRAM Cuts (20)
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files and All EDA views
Tested design flows: Simulation, Physical Verification
Technical Documents: Generic Datasheets
98
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; anuj[at]scl[dot]gov[dot]in;basra[at]scl[dot]gov[dot]in
Memory IP: Standard 6LM DPRAM Cuts (20)
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files and All EDA views
Tested design flows: Simulation, Physical Verification
Technical Documents: Generic Datasheets
99
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; asim[at]scl[dot]gov[dot]in;manojkr[at]scl[dot]gov[dot]in
Analog IP: CMOS Temperature Sensor1 (3.3V PowerSupply,4mV/°C,1.25V typical output)
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Simulation Datasheet
100
Provider Name: SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; asim[at]scl[dot]gov[dot]in;manojkr[at]scl[dot]gov[dot]in
Analog IP: CMOS Temperature Sensor2 (3.3V Power Supply,11mV/°C, 750V typical output)
Maturity Level: Silicon Proven
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Datasheet
101
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; asim[at]sc[dot]gov[dot]in;rajiv[dot]bhatia[at]scl[dot]gov[dot]in;manojkr[at]scl[dot]gov[dot]in
Analog IP: Temperature Compensated Oscillator (128 KHz)
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Simulation Datasheet
102
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; asim[at]scl[dot]gov[dot]in
Analog IP: Current Feedback Instrumentation Amplifier (Programmable gain upto 32 V/V)
Maturity Level: Silicon Proven
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents:Datasheet
103
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; sehgal[at]scl[dot]gov[dot]in;anil[at]scl[dot]gov[dot]in
Analog IP: LDO1 (1.8V/12mA)
Maturity Level: Silicon Proven
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Datasheet
104
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; sehgal[at]scl[dot]gov[dot]in;anil[at]scl[dot]gov[dot]in
Analog IP: LDO2 (1.8V/150mA)
Maturity Level: Silicon Proven
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Datasheet
105
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; sehgal[at]scl[dot]gov[dot]in;anil[at]scl[dot]gov[dot]in
Analog IP: Voltage Reference (3.3V Power Supply, 1.17 V)
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Simulation Datasheet
106
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; sehgal[at]scl[dot]gov[dot]in;anil[at]scl[dot]gov[dot]in
Security IP: Integer Phase Locked Loop (PLL) (Clock generation up to 1.2 GHz)
Maturity Level: Silicon Proven
Provided with core: Design Files (netlist & gds)
Tested design flows: Physical Verification
Technical Documents: Datasheet
107
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; ashutosh[at]scl[dot]gov[dot]in;averma[at]scl[dot]gov[dot]in
Analog IP: POR1
Maturity Level: Silicon Proven(In other Products)
Provided with core: Design Files (netlist & gds)
Tested design flows: FE & BE Design, Simulation, Physical Verification
Technical Documents: Simulation Datasheet
108
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; sunilk[at]scl[dot]gov[dot]in
Sysetm/Peripheral IP: SPI Controller
Maturity Level: Silicon Proven
Provided with core: Design Files (RTL, constraint file)
Tested design flows: FE & BE Design, Synthesis, Simulation, Physical Verification
Technical Documents: Datasheet
109
Provider Name:SCL
IP Type:Hard IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in;pooja[at]scl[dot]gov[dot]in
Processor IP: 8-Bit Microcontroller
Maturity Level: Silicon Proven
Provided with core: Design Files (RTL, constraint file)
Tested design flows: FE & BE Design, Synthesis, Simulation, Physical Verification
Technical Documents: Datasheet
110
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: PCIe Gen2
Maturity Level: Silicon Proven
Provided with core:Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+, 55nm TSMC, 55LP, TSMC 65G
111
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: PCIe Gen3/2/1
Maturity Level: Silicon Proven
Provided with core:Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55nm TSMC, GF 28SLP, Samsung 28SLP, 55LP, TSMC 65G
112
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: PCIe Gen4/3/2/1
Maturity Level: Others (CAD proven)
Provided with core:Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, GF 28SLP, Samsung 28SLP
113
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: PCIe Gen5/4/3/2/1 *
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+
114
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: USB 3.1/3.0
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+, GF 28SLP
115
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: USB 3.2 GEN2 single lane
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+, 55LP, TSMC 65G
116
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: USB 3.2 Gen2 Quadlane
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+
117
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: USB 3.2 Gen2 2x2
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+, 55LP, TSMC 65G
118
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Serdes 10G *
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+, 55nm TSMC, GF 28SLP, 55LP, TSMC 65G
119
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Serdes 16G
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+
120
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Ethernet_56G
Maturity Level: Others (under development)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm
121
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Ethernet_10G
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55nm TSMC, TSMC 65G
122
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Ethernet 1G Base T
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+
123
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Ethernet 1G Base T
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, TSMC 22nm
124
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Etherrnet 10G Base T
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+
125
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: Ethernet 10G Base T
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+
126
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Interface/Connectivity IP: MIPI MPHY_Gear4
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+, 55nm TSMC
127
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL 32 gbps
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+
128
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL_16GHz
Maturity Level: Others (CAD proven)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+
129
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL_10_GHz
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55nm TSMC, GF 28SLP, 55LP, TSMC 65G
130
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL_8_GHz
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55nm TSMC, GF 28SLP, TSMC 65G
131
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL_5_GHz
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, GF 28SLP, Samsung 28SLP, 55LP, TSMC 65G
132
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL_2.5_GHz
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, TSMC 65G
133
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL_4GHz
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, GF 28SLP, Samsung 28SLP
134
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: PLL_6_8GHz
Maturity Level: Others (developed)
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, GF 28SLP
135
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: CDR_16G
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+
136
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: CDR_10G
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, GF 28SLP, Samsung 28SLP, 55LP, TSMC 65G
137
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: CDR_8G
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55nm TSMC, GF 28SLP, Samsung 28SLP, TSMC 65G
138
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: CDR_5G
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55nm TSMC, GF 28SLP, Samsung 28SLP, 55LP, TSMC 65G
139
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: BGR_0.9V
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+
140
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: BGR_1.0V
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55nm TSMC, GF 28SLP, Samsung 28SLP
141
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: BGR_1.2V
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 12nm, 28nm TSMC HPC/+, 55LP, TSMC 65G
142
Provider Name:Terminus Circuits
IP Type:Hard IP
Support: sales[at]terminuscircuits[dot]com
Analog IP: BGR_1.8V
Maturity Level: Silicon Proven
Provided with core: Standard IP deliverable: flat encrypted GDS,LVS compatible CDL, LEF, Inegraion guideline
Tested design flows: All our licensed IP are silicon proven at our end or at customer site
Technical Documents: Datasheets/Product briefs
Process Nodes Available: 28nm TSMC HPC/+
143
Provider Name:SCL
IP Type:Soft IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in; sunilk[at]scl[dot]gov[dot]in
Sysetm/Peripheral IP: SPI Controller
Maturity Level: Silicon Proven
Provided with core: Design Files (RTL, constraint file)
Tested design flows: FE & BE Design, Synthesis, Simulation, Physical Verification
Technical Documents: Datasheet
144
Provider Name:SCL
IP Type:Soft IP
Support: shilpa[at]scl[dot]gov[dot]in;harsh[at]scl[dot]gov[dot]in;pooja[at]scl[dot]gov[dot]in
Processor IP: 8-Bit Microcontroller
Maturity Level: Silicon Proven
Provided with core: Design Files (RTL, constraint file)
Tested design flows: FE & BE Design, Synthesis, Simulation, Physical Verification
Technical Documents: Datasheet

Accessibility Options

Adjust Font Size

100%
Highlight Links
Highlight Titles
Text Spacing
Line Height
Text Alignment
Df
Dyslexia Font

Color Adjustments

Light Theme
Invert Colors

Other Accessibility Features

Pause Animations
Hide Images
Custom Cursor
Text to Speech
ADHD Mode
